S-350
We are the professional switching power supply supplier,good quality with competitive price,welcome to contact us for enquiry.
| |||||||||||
Model | S-350-5 | S-350-7.5 | S-350-12 | S-350-13.5 | S-350-15 | S-350-24 | S-350-27 | S-350-48 | |||
OUTPUT | DC Voltage | 5V | 7.5V | 12V | 13.5V | 15V | 24V | 27V | 48V | ||
Voltage Tolerance | ±2% | ±2% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | |||
Rated Current | 50A | 40A | 29A | 25.8A | 23.2A | 14.6A | 13A | 7.3A | |||
Current Range | 0-50A | 0-40A | 0-29A | 0-25.8A | 0-23.2A | 0-14.6A | 0-13A | 0-7.3A | |||
Rated Power | 250W | 300W | 348W | 348.3W | 348W | 350.4W | 351W | 350.4W | |||
Ripple & Noise | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | |||
DC Adjustment Range | -10%，+12% | ±20% | -16%，+10% | -12%，+11% | -10%，+20% | -16%，+10% | -4%，+18% | -15%，+17% | |||
Setup,Rise,Hold Time | 200ms,50ms,20ms at full load | ||||||||||
INPUT | Voltage Range | 90～132 VAC/180～264VAC47～63 Hz；selected by switch 254～370VDC | |||||||||
AC Current | 6.5A/115 V 4A/ 230 V | ||||||||||
Efficiency | 74% | 76% | 76% | 79% | 78% | 81% | 82% | 83% | |||
Inrush Current | Cold start 50A/115V50A/230V | ||||||||||
Leakage Current | ＜3.5 mA/240VAC | ||||||||||
PROTECTION | Over Load | 105%～135% | |||||||||
Protection type: Fold back current limiting, recovers automatically after fault condition is removed. | |||||||||||
Over Voltage | 115%～135% | ||||||||||
Protection type: Voltage liminting, recovers automatically after fault condition is removed. | |||||||||||
Over Temp. | RT3≥55℃ FAN ON，≤45℃ FAN OFF，≥80℃ output shutdown (5~7.5V) | ||||||||||
RT3≥65℃ FAN ON，≤55℃ FAN OFF，≥80℃ output shutdown (12~15V) | |||||||||||
RT3≥70℃ FAN ON，≤60℃ FAN OFF，≥85℃ output shutdown (24~48V) | |||||||||||
OUTPUT | Withstand Voltage | -10℃～+60℃；20%～90 %RH | |||||||||
Isolation Resistance | -20℃～+85℃；10%～95 %RH | ||||||||||
Safety Standard | 10～500Hz，2G 10min./1cycle，period for 60min, each along X, Y, Z axes | ||||||||||
SAFETY | EMC Standard | I/P-O/P: 1.5KVACI/P-FG: 1.5KVACO/P-FG: 0.5KVAC | |||||||||
Weight | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC | ||||||||||
STANDARD | Packing | Design refer to UL1950 | |||||||||
DC Voltage | Drsign refer to FCC Part15 J Conduction Class A | ||||||||||
OTHERS | Voltage Tolerance | 1.1.5Kg | |||||||||
Rated Current | 12pcs/14.3Kg/0.93CUFT | ||||||||||
NOTE | 1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2.Ripple & noise are measured at 20MHz of bandwidth by using a 12″twisted pair-wire terminated with a 0.1μ &47μ parallel capacitor. 3.Tolerance: includes set up tolerance, line regulation and load regulation | ||||||||||
