Model

S-50-5

S-50-12

S-50-15

S-50-24

DC Voltage

5V

12V

15V

24V

48V

Voltage Tolerance

±2%

±1%

±1%

±1%

±1%

Rated Current

10A

4.2A

3.4A

2.1A

1A

Current Range

0-10A

0-4.2A

0-3.4A

0-2.1A

0-1A

Rated Power

50W

50.4W

51W

50.4W

48W

Ripple & Noise

75mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

DC Voltage Adj. Range

+10,-5%

±10%

±10%

±10%

±10%

Setup, Rise, Hold time

Setup,Rise,Hold Time 200ms,100ms,20ms at full load

Input

Voltage Range

85～132 VAC/170～264VAC47～63 Hz；selected by switch240～370VDC

AC Current

1.3A/115 V 0.65A/ 230 V

Efficiency

71%

78%

78%

82%

84%

Inrush Current

Cold start18A/115V 36A/230V

Leakage Current

＜1 mA/240VAC

Protection

Over Load

110%～160%

Protection type: Fold back current limiting, recovers automatically after faultlt condition is removed

Environment

Working Temp. & Humidity

-10℃～+60℃；20%～90 %RH

Storage Temp. & Humidity

-20℃～+85℃；10%～95 %RH

Vibration

10～500Hz，2G 10min./1cycle，period for 60min, each along X, Y, Z axes

Safety

Withstand Voltage

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

Standards

Safety Standard

Design refer to UL1012

EMC Standard

Design refer to FCC Part15 J Conduction Class B

Others

Weight

0.51Kg

Packing

30pcs/15.8Kg/0.99CUFT

Remarks
