Model

CH1

CH2

CH2

CH3

Output

DC Voltage

5V

12V

-5V

5V

12V

-12V

5V

15V

-15V

Voltage Tolerance

±2%

±6%

±8%

±2%

±6%

±8%

±2%

±6%

±6%

Rated Current

3A

2A

0.5A

3A

2A

0.5A

3A

1.5A

0.5A

Current Range

0.6-5A

0.2-3A

0.1-1A

0.6-5A

0.2-3A

0.1-1A

0.6-5A

0.2-2A

0.1-1A

Rated Power

41.5W

45W

45W

Ripple & Noise

100mVp-p

120mVp-p

100mVp-p

100mVp-p

120mVp-p

120mVp-p

100mVp-p

120mVp-p

120mVp-p

DC Voltage Adj. Range

CH1：-5%，+10%

Setup, Rise, Hold time

800ms,50ms,60ms/230VAC 1.6ms,50ms,16ms/115VAC full load

Input

Voltage Range

85～264 VAC / 47～63 Hz；120～370VDC

AC Current

1.2A/115 V 0.7A/ 230 V

Efficiency

72%/115VAC

72%/115VAC

72%/115VAC

Inrush Current

Cold start 20A/115V 40A/230V

Leakage

＜3.5mA/240VAC

Protection

Over Load

105%～150% /115VAC

Protection type：shut down o/p voltage，intermittent auto-recovery after fault condition is removed.

Over Voltage

5V:115%~135%

Protection type：Hiccup mode, re-power on to recover

Environment

Working Temp. & Humidity

-10℃～+60℃；20%～90 %RH

Storage Temp. & Humidity

-20℃～+85℃；10%～95 %RH

Vibration

10～500Hz，2G 10min./1 cycle，period for 60min，each along X,Y,Z axes

Safety

Withstand Voltage

I/P-O/P：3KVAC I/P-FG：1.5KVAC O/P-FG：0.5KVAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG：100M Ohms/500VDC

Standards

Safety Standard

Design refer to CSA 950, (UL1950, IEC950, TUV EN60950)

EMC Standard

Design refer to EN55022 (CISPR22), EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11; ENV50204

Others

Weight

0.44Kg

Packing

45pcs/19.8Kg/1.22CUFT

Remark

1. All parameters not specially mentioned are measured at 230VAC input, rated load and 25℃of ambient temperature.
2. Ripple & Noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1μ&47μparallel capacitor.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equpment must be re-confirmed that it still meets EMC directives.
5. Concrete output current see Derating Curve.
