Model

Q-60B

Q-60C

Q-60D

CH1

CH2

CH3

CH4

CH1

CH2

CH3

CH4

CH1

CH2

CH3

CH4

Output

DC Voltage

5V

12V

-5V

-12V

5V

15V

-5V

-15V

5V

12V

24V

-12V

Voltage Tolerance

±2%

±6%

±5%

±5%

±2%

+8,-4%

±5%

±5%

±2%

±6%

+8,-4%

±5%

Rated Current

5.5A

2A

0.5A

0.5A

5.5A

1.5A

0.5A

0.5A

4A

1A

1A

0.5A

Current Range

0.5-8A

0.1-3A

0-1A

0-1A

0.5-8A

0.1-3A

0-1A

0-1A

0.5~8A

0.1~3A

0.1~1.5A

0~1A

Rated Power

60W

60W

62W

Ripple & Noise

100
mVp-p

120
mVp-p

100
mVp-p

120
mVp-p

100
mVp-p

120
mVp-p

100
mVp-p

120
mVp-p

100
mVp-p

120
mVp-p

150
mVp-p

120
mVp-p

DC Voltage Adj. Range

CH1：-5%，+10%

Setup, Rise, Hold time

1600ms,20ms,12ms/115VAC 800ms,20ms, 60ms/230VAC full load

Input

Voltage Range

85～264 VAC 47-63Hz；120～370VDC

AC Current

2A/115 V 0.8A/ 230 V

Efficiency

70%

72%

75%

Inrush Current

Cold start 18A/115V 36A/230V

Leakage Current

＜1 mA/240VAC

Protection

Over Load

105%～150% /115VAC

Protection type: shut down o/p voltage，intermittent auto-recovery after fault condition is removed

Over Voltage

5V:115%～135%

Protection type: Hiccup mode, recovers automatically after fault condition is removed.

Enviroment

Working Temp. & Humidity

-10℃～+60℃；20%～90 %RH

Storage Temp. & Humidity

-20℃～+85℃；10%～95 %RH

Vibration

10～500Hz，2G 10min./1 cycle，period for 60min，each along X,Y,Z axes

Safety

Withstand Voltage

I/P-O/P：3KVAC I/P-FG：1.5KVAC O/P-FG：0.5KVAC

Isolation Resisitance

I/P-O/P，I/P-FG，O/P-FG： 100M Ohms/500VDC

Standards

Safety Standard

Design refer to UL60950

EMC Standard

Design refer to EN55022,EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11; ENV50204

Others

Weight

0.56Kg

Packing

30pcs/17.3Kg/0.99CUFT

Remark

1. All parameters not specially mentioned are measured at 230VAC input, rated load and 25℃of ambient temperature.
2. Ripple & Noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1μ&47μparallel capacitor.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equpment must be re-confirmed that it still meets EMC directives.
5. Concrete output current see Derating Curve.
